Chapter 3: Installing the Inverter

Install the inverter either before or after the modules and power optimizers have been

installed.

Inverter Package Contents

One StorEdge inverter

One mounting bracket

Two Allen screws for fastening the inverter to the mounting bracket

SolarEdge activation card

One 9V battery

Installation guide (with activation card and instructions)

Chapter 3: Installing the Inverter 31

StorEdge Solution with Backup MAN-01-00262-1.5
