Chapter 2: Installing the Power Optimizers

Safety

The following notes and warnings apply when installing the power optimizers. Some of

the following may not be applicable to smart modules:

WARNING!

The metallic enclosure of the power optimizer must be grounded in accordance

with the product's listing and local and national codes.

 AVERTISSEMENT!



L'enceinte métallique de l’optimiseur de puissance doit être mise à la terre en

accord avec les régulations locales et nationales.

StorEdge Solution with Backup MAN-01-00262-1.5

20 Chapter 2: Installing the Power Optimizers
