Auto-Transformer Technical Specifications



 SEAUTO-TX-5000 

ELECTRICAL RATINGS  

Rated Power - Continuous 5000 VA

Rated Power - Peak 7600 for 10 sec VA

Output Voltage 120/ 240 Split Phase V

Max Continuous Output Current per Phase

@120V

25 A

Split Phase Imbalance (@ Rated Power)

Up to 25A difference

between phases



Thermal Protection Yes 

INSTALLATION SPECIFICATIONS  

AC Output conduit size / AWG range 0.75 / 14-10

in/ AWG

Dimensions (HxWxD) 6.7 x 7.9 x 5.5 / 170 x 200 x 140 in / mm

Weight 29.7 / 13.5 lb / kg

Min - Max Operating Temperature -13 to +140 / -25 to +60 °F / °C

Protection Rating NEMA 3R 

Installation Wall mounted 


