Installation Guide


SE3800A-US
(1)
SE7600A-US
(1)
Unit
STANDARD COMPLIANCE
Safety
 UL1741,UL1741 SA, UL1699B, UL1998, CSA
22.2

Grid Connection Standards  IEEE1547, Rule 21, Rule 14H 
Emissions  FCC part15 class B 
INSTALLATION SPECIFICATIONS
AC Output (Loads/Grid) conduit
size / AWG range
 1” / 14-6 AWG in/AWG
AC Output (Backup) conduit
size / AWG range
 0.75-1” drill guides / 14-6 AWG in/AWG
AC Input (Auto-transformer)
conduit size / AWG range
 0.75-1 ” / 14-6 AWG in/AWG
DC Input (PV) conduit size /
AWG range
 0.75 ” / 14-8 AWG in/AWG
DC Input (Battery) conduit size /
AWG range
 0.75” / 12-10 AWG in/AWG
Dimensions with Connection
Unit (HxWxD)
 37 x 12.5 x 7.2 / 940 x 315 x 184 in / mm
Weight with Connection Unit  58.5 / 26.5 lb / kg
Cooling
 Natural convection and internal fan (user
replaceable)

Noise  < 50 dBA
Min - Max Operating
Temperature
 -13 to +140 / -25 to +60 °F / °C
Protection Rating  NEMA 3R 
(1)
These specifications apply to inverters with part numbers SE3800A-USS2XXXXX or SE7600A-USS2XXXXX and
connection unit model number BCU-1PH-USS.
StorEdge Single Phase Inverter with Connection Unit for High Power
Technical Specifications 151
StorEdge Solution with Backup MAN-01-00262-1.5
