Installation Guide


SE3800A-US
(1)
SE7600A-US
(1)
Unit
INPUT - DC (PV)
Maximum DC Power (STC) 5100 10250 W
Max Input Current
(2)
13 23 Adc
2-pole Disconnection  Yes 
INPUT - DC (BATTERY)
Supported Battery Types  LG Chem RESU10H 
Number of Batteries per Inverter
1 or 2
(3)

Continuous Power 5000 W
Peak Power 7000 W
Max Input Current 17.5 
DC Fuses on Plus and Minus 25A (field replaceable) 
2-pole Disconnection  Yes
ADDITIONAL FEATURES
Supported Communication
Interfaces
 RS485 for battery, RS485, Ethernet, Cellular,
ZigBee (optional)

Revenue Grade Data, ANSI C12.1  Optional
(4)

Integrated AC, DC and
Communication Connection
Unit
 Yes 
AC Disconnect
 Yes 
Manual Inverter Bypass Switch
 Yes 
DC Voltage Rapid Shutdown (PV
and Battery)
 Yes, according to NEC 2014 and 2017 690.12
(5)

Auto-transformer thermal
protection
 Yes 
(1)
These specifications apply to inverters with part numbers SE3800A-USS2XXXXX or SE7600A-USS2XXXXX and
connection unit model number BCU-1PH-USS.
(2)
A higher current source may be used; the inverter will limit its input current to the values stated.
(3)
When connecting two LG Chem batteries, each battery must have a different part number; supporting SolarEdge
firmware is required.
(4)
Revenue grade inverter P/N: SExxxxA-USS2xxxYx or SExxxxA-USS2xxxMx
(5)
If the inverter is located in a place that is not easily accessible by emergency responders (according to the National
Electrical Code, 2017), an external shutdown switch must be installed. Use inverters with PN SExxxxA-USS2R.
StorEdge Solution with Backup MAN-01-00262-1.5
150 StorEdge Inverter
