Installation Guide


SE3800A-US
(1)
SE7600A-US
(1)
Unit
AC Output Voltage Min-Nom-
Max (L-N)
 105-120-132 Vac
AC Frequency Min-Nom-Max  55 - 60 - 65 Hz
Maximum Continuous Output
Current @240V - Backup Mode
 21 A
Max Continuous Output Current
per Phase @120V
 25 A
GFDI  1 A
AC Circuit Breaker  Yes 
THD  < 5 %
Power factor with rated power  0.2 leading to 0.2 lagging 
Automatic switchover time  < 2 sec
INPUT - DC (PV and BATTERY)
Transformer-less, Ungrounded  Yes 
Max Input Voltage  500 Vdc
Nom DC Input Voltage  400 Vdc
Reverse-Polarity Protection  Yes 
Ground-Fault Isolation
Detection
 600kΩ Sensitivity 
Maximum Inverter Efficiency  98 %
CEC Weighted Efficiency  97.5 %
(1)
These specifications apply to inverters with part numbers SE3800A-USS2XXXXX or SE7600A-USS2XXXXX and
connection unit model number BCU-1PH-USS.
StorEdge Single Phase Inverter with Connection Unit for High Power
Technical Specifications 149
StorEdge Solution with Backup MAN-01-00262-1.5
