Installation Guide

StorEdge Single Phase Inverter with
Connection Unit for High Power Technical
Specifications
StorEdge Inverter

SE3800A-US
(1)
SE7600A-US
(1)
Unit
OUTPUT - AC (LOADS/GRID)
Rated AC Power Output 3800 7600 VA
Max AC Power Output 4175 8350 VA
AC Output Voltage Min-Nom-
Max (L-L)
(2)
 211-240-264 Vac
AC Frequency Min-Nom-Max
(1)
 59.3 - 60 - 60.5 Hz
Maximum Continuous Output
Current @240V
16 32 A
GFDI 1 A
Utility Monitoring, Islanding
Protection, Country
Configurable Thresholds
Yes 
Charge Battery from AC (if
Allowed)
Yes 
THD < 3 %
Power factor with rated power 1 (adjustable from -0.85 to +0.85) 
OUTPUT - AC (BACKUP POWER)
(3)
Rated AC Power Output
 5000
(4)
VA
Max AC Power Output - Surge 7000 for 10 sec
4
VA
AC Output Voltage Min-Nom-
Max (L-L)
 211-240-264 Vac
(1)
These specifications apply to inverters with part numbers SE3800A-USS2XXXXX or SE7600A-USS2XXXXX and
connection unit model number BCU-1PH-USS.
(2)
For other regional settings, contact SolarEdge Support.
(3)
Not designed for standalone applications and requires AC for commissioning.
(4)
The rated AC power output is the minimum between the AC Power Output and the battery continuous peak power.
StorEdge Solution with Backup MAN-01-00262-1.5
148 StorEdge Single Phase Inverter with Connection Unit for High Power
Technical Specifications
