Appendix F: Powering the LG Chem Battery Off

and On

The LGChem battery must be powered off and on at different stages of the inverter

installation.

LGChem batteries are available with either of the following two types of powering

mechanism design:

With the disconnect switch (requires Firmware version 3.24xx or later):

With the auxiliary power switch:

To power off the battery:

1. Turn off the circuit breaker.

2. Turn off the disconnect/auxiliary power switch.

To power the battery back on:

1. Turn on the disconnect/auxiliary power switch.

2. Turn on the circuit breaker.

Appendix F: Powering the LG Chem Battery Off and On 147

StorEdge Solution with Backup MAN-01-00262-1.5
