Installation Guide

Error
Code
LCD Message Cause and Troubleshooting
1Dx31
Power overload
OFF and ON to resume
Inverter output is overloaded or
output current is higher than
battery max allowed output. The
inverter tried to restart 3 times.
1Dx32
Backup init over voltage
External voltage source on
backed-up loads when
operating in Backup mode.
Disconnect all external voltage
sources on backed-up loads.
Inverter internal error. Contact
SolarEdge support.
1Dx35
Internal CB down
Make sure that the loads do not
consume higher current than
the inverter max output current.
Open the inverter StorEdge
Connection Unit and switch the
main circuit breaker to the ON
position.
System Warnings
Warnings are displayed in the initial status screen with the format: <Warning X>. For
example:
V a c [ V ] V d c [ V ] P a c [ W ]
1 . 0      0 . 5      0 . 0
P _ O K : X X X / Y Y Y < S _ O K >
W a r n i n g 8         O N
The warning is a status screen. To view the warning description, press the LCD button.
The following is a list of system warnings:
StorEdge Solution with Backup MAN-01-00262-1.5
134 StorEdge Error Codes
