Error
Code
LCD Message Cause and Troubleshooting
digital board in the inverter.
Check that the StorEdge
Connection Unit LEDs are ON.
1Dx27
Connection Unit
Temp. Too High
Inverter production stopped due
to StorEdge Connection Unit
overheating or due to internal
fan malfunction.
Clean the StorEdge Connection
Unit fan
If the fan is malfunctioning,
replace the fan
1Dx2D
Meter Comm. Error
Refer to
Troubleshooting
on
page 123.
1Dx2E
Battery Comm Error
Check the wiring to the battery
and the battery DIPswitch
configuration (refer to
Connecting to the Battery
on
page 59 and
DIPSwitch Setup
on page 64).
Connecting to the Battery
on
page 59
Check the battery setup in the
RS485-Conf screen (refer to
Configuring the RS485 Bus for
Battery and Meter Connection
on page 111).
Appendix A: Troubleshooting 133
StorEdge Solution with Backup MAN-01-00262-1.5
