StorEdge Connection Unit LEDs

There are three LEDs on the lower board of the StorEdge Connection Unit, near the DIP

switches:

Figure 44: StorEdge Connection Unit LEDs

In normal operation, the middle and bottom LEDs indicate auxiliary voltages (13V

from DC/DC, 5V and 3.3V) and should always be lit.

The top LEDshould be lit when the inverter DC voltage is at least 200 Vdc (check

when both inverter ON/OFFswitch and StorEdge Connection Unit switch are ON).

You can check the status screen for the Vdc value.

If all LEDs are OFF:

Check that AC voltage exists in the inverter

Check that the communication cable between the StorEdge Connection Unit

and the digital board is properly connected.

If the top LED is ON, and middle and bottom LEDs are off - an internal failure has

occurred. Contact SolarEdge support.

Appendix A: Troubleshooting 127

StorEdge Solution with Backup MAN-01-00262-1.5
