Installation Guide

and the total AC output power produced (Pac):
V a c [ V ] V d c [ V ] P a c [ W ]
2 4 0 . 7 w 3 7 1 . 9 2 3 4 9 . 3
P _ O K : X X X / Y Y Y < S _ O K >
                       O N
To test Backup:
1.
Disconnect the ACpower by shutting off the AC at the main distribution panel. The
inverter should disconnect from the grid, and continue supplying power to the
backed-up loads.
Switching to Backup mode takes a few seconds. The LCD screen will show the
Backup mode is ON:
V a c [ V ] V d c [ V ] P a c [ W ]
2 4 0 . 7  3 7 1 . 9   2 3 4 9 . 3
P _ O K : X X X / Y Y Y < S _ O K >
B a c k u p M o d e        O N
2.
Press the external LCD light button to display the battery status screen, and check
that:
The battery State is: Discharging / Charging
The SOEpercentage is decreasing/ increasing. If SOE is below 10%, refer to
Additional StorEdge Troubleshooting on page 128.
The PWR value is greater than 0
B S N : X X X X X X X X I D : 2 4
S O E : 8 9 %      P W R : 3 W
T o t a l : < x > W h
S t a t e :  D i s c h a r g i n g
3.
Turn the AC back ON from the main distribution panel. The inverter should
reconnect loads back to the grid.
To test the Maximize Self-consumption mode:
1. Verify the inverter ON/OFF switch is ON.
2. Turn on as many loads so that consumption is greater than the inverter's maximum
AC power.
3.
Press the inverter LCD light button to display the Meter status screen and check that
import power is greater than zero:
