Creating an Ethernet (LAN) Connection

This communication option enables using an Ethernet connection to connect the

inverter to the monitoring platform through a LAN.

Ethernet cable specifications:

Cable type – a shielded Ethernet cable (Cat5/5E STP) may be used

Maximum distance between the inverter and the router – 100 m/ 330 ft.

NOTE

If using a cable longer than 10 m / 33 ft in areas where there is

a risk of induced voltage surges by lightning, it is recommend

to use external surge protection devices.

For details refer to:

https://www.solaredge.com/sites/default/files/overvoltage_surge_

protection_na.pdf.

Figure 35: Example of Ethernet connection

Chapter 9: Setting Up Communication to the Monitoring Platform 101

StorEdge Solution with Backup MAN-01-00262-1.5
