ZigBee

This option enables wireless connection of one or several devices to a

ZigBee Gateway, for wireless communication to the monitoring platform.

The ZigBee Gateway is provided with an installation guide, which should

be reviewed prior to connection. Refer to

https://www.solaredge.com/sites/default/files/se-zigbee-home-gateway-

installation-guide.pdf.

Communication Connectors

Two communication glands are used for connection of the various communication

options. Each gland has three openings. The table below describes the functionality of

each opening. Unused openings should remain sealed.

Gland# Opening Functionality Cable size (diameter)

1 (PG16)

One small External antenna cable 2-4 mm

Two large

Ethernet connection

(CAT5/6), ZigBee, or

Cellular

4.5-7 mm

2 (PG13.5) All three RS485 2.5-5 mm

Figure 33: Communication Glands

The communication board has a standard RJ45 terminal block for Ethernet connection,

and a 9-pin terminal block for RS485 connection, as shown below:

Chapter 9: Setting Up Communication to the Monitoring Platform 99

StorEdge Solution with Backup MAN-01-00262-1.5
