RS485
RS485 is used for the connection of multiple SolarEdge devices on the same bus in a
master-slave configuration. RS485 can also be used as an interface to external devices,
such as meters and third party data loggers.
RS485-1: Enables the connection of multiple devices (inverters/Commercial
Gateway)over the same bus, such that connecting only one device to the
Internet is sufficient to provide communication services for all the devices
on the bus.
RS485 Plug-in: Purchased separately, the RS485 Plug-in
provides an additional RS485 port (referred to as RS485-E) for
the inverter for enhanced communications. The plug-in is a 3
pin terminal block which is installed on the communication
board. This kit is provided with an installation guide, which
should be reviewed prior to connection see,
https://www.solaredge.com/sites/default/files/RS485_expansion_kit_installation_
guide.pdf
For connection instructions refer to Creating an RS485 Bus Connection on page 91
For connection instructions refer to .
Cellular (GSM, CDMA)
This wireless communication option (purchased separately) enables
using a cellular connection to connect one or several devices (depending
on the data plan used) to the monitoring platform.
The GSM/CDMA Plug-in is provided with a user manual, which should be
reviewed prior to connection. Refer to
https://www.solaredge.com/sites/default/files/cellular_gsm_installation_
guide.pdf
and https://www.solaredge.com/sites/default/files/cellular_cdma_kit_
installation_guide_na.pdf.
