LOCAL - The power is controlled locally (e.g. by a fixed limit), or this

inverter limits the PV power production to its relative portion of the

feed-in power limit, as a result of disconnected communication with the

smart energy manager. If this status appears, check the communication

to the smart energy manager or the communication to the meter.

PWR Limit: The inverter maximum output power set by one of the power

limiting options:

RRCR

Smart energy manager (Feed-in limitation)

P(f)

P(U)

Q(U)

Cos Phi: The ratio between active to reactive power

Power Prod: The power produced by the inverter

For more information, refer to the

Power Control Application Note

available on the SolarEdge website at

http://www.solaredge.us/files/pdfs/application_note_power_control_

configuration.pdf.

-Three Phase System Installation Guide MAN-01-00002-4.3

82 Status Screens - Operational Mode
