P A N : X X X X X
C H : X X / X X X X R S S I : < L >
M I D : X X X X X X
RSSI: The receive signal strength indication of the closest ZigBee in the system.
L = low, M = medium, H = high and (-) = no signal.
PAN ID: The ZigBee transceiver PAN ID (Personal Area Network Identification),
the IDuniquely represents a device in a Zigbee network.
Ch.: The ZigBee transceiver channel
ID: The ZigBee transceiver ID
MID: The Master ID of the coordinator (master) ZigBee Plug-in. This field is
shown only in devices with router (slave) ZigBee cards, and after a successful
ZigBee association. If a ZigBee Plug-in is not connected, a No ZigBee message
is displayed instead of the MID field.
Cellular Status
If a cellular (CDMA)Plug-in is connected, this screen replaces the Server status screen:
S e r v e r : C e l l < S _ O K >
S t a t u s : < O K >
M N O : < X X X X X X > S i g : 5
< E r r o r m e s s a g e >
Server: The method of communication to the SolarEdge monitoring platform.
Should display Cell.
Status: Displays OK if the inverter established a successful physical connection
to the Cellular Plug-in.
S_OK: The last communication to the SolarEdge monitoring platform was
successful (appears if the inverter is connected to the platform).
Sig: The signal strength, received from the Cellular Plug-in. A value between 0-
5, (0 = no signal, 5 = excellent signal).
Error message per communication connection status failure
GSMStatus
If a GSM Plug-in is connected, this screen replaces the Server status screen:
S e r v e r : C e l l < S _ O K >
S t a t u s : < O K >
M N O : < x x x x x x x > S i g : 5
< E r r o r m e s s a g e >
-Three Phase System Installation Guide MAN-01-00002-4.3
78 Status Screens - Operational Mode
