CPU: The communication board firmware version
Country: the current country setting
Server Communication Status
S e r v e r : L A N  < S _ O K >
S t a t u s :       < O K >
    x x x x x x x x
< E R R O R M E S S A G E >
NOTE
If the connection method is CDMA (referred to as "Cellular" in the status
screens)or GSM, the server screen is replaced with the Cellular or GSM status
screens (see Cellular Status on page 78 and GSMStatus on page 78).
Server: The method of connection to the SolarEdge monitoring platform.
S_OK: The connection to the SolarEdge monitoring platform is successful
(should appear only if the inverter is connected to the server).
Status: Displays OK if the inverter established successful connection and
communication with the specified server port/device (LAN, RS485 or ZigBee
Plug-in).
xxxxxxxx: Eight-bit Ethernet communication connection status: A string of 1s
and 0s is displayed. 1 indicates OK, 0 indicates an error. For a list of the possible
errors and how to troubleshoot them, refer to Troubleshooting Communication
on page 96
Error message, according to failure. Refer to
https://www.solaredge.com/sites/default/files/troubleshooting_for_se_
inverter_insallation_guide_addendum_na.pdf.
IP Status
This screen describes the Ethernet configuration: IP, Mask, Gateway and MAC address
(Media Access Control) of the Inverter.
I P 1 9 2 . 1 6 8 . 2 . 1 1 9
M S K 2 5 5 . 2 5 5 . 2 5 5 . 0
G W 1 9 2 . 1 6 8 . 2 . 1
M A C 0 - 2 7 - 0 2 - 0 0 - 3 9 - 3 6
ZigBee Status
This screen describes the ZigBee configuration:
