Installation Guide

NOTE
SolarEdge inverters with “Grid Support” functionality (as marked on the
inverter certification label), are compliant with UL1741 Supplement A. The
functionality is built into the inverter and no additional external device is
required.
Display
Select Display to set the following:
T e m p e r a t u r e < C >
L C D O n T i m e < 3 0 >
T L M O n T i m e < 1 5 >
Temperature: Select Celsius or Fahrenheit units.
LCD On Time <30>: The number of seconds that the LCD backlight is ON after
pressing the LCD light button. Set a value within the range of 10-120 seconds.
TLM On Time <15>: The number of minutes that the LCD backlight is ON while
viewing the Telemetry window. Set a value within the range of 1-120 minutes.
Maintenance
Select Maintenance to set the following options:
D a t e a n d T i m e
R e s e t C o u n t e r s
F a c t o r y R e s e t
F W U p g r a d e
A F C I < D i s >
D i a g n o s t i c s
S t a n d b y M o d e
G r i d P r o t e c t i o n
B o a r d R e p l a c e m e n t
Date and Time: Set the internal real-time clock. If connected to the SolarEdge
monitoring platform, the date and time are set automatically and only time zone
should be set.
Reset Counters: Resets the accumulated energy counters that are sent to the
SolarEdge monitoring platform
Factory Reset: Performs a general reset to the default device settings.
FW Upgrade: Perform a software upgrade by using an SD card.
Refer to upgrading_an_inverter_using_micro_sd_card.pdf.
Chapter 6: User Interface 71
Three Phase System Installation Guide MAN-01-00002-4.3
