Installation Guide

RS232 Conf
(1)
:
D e v i c e T y p e < S E >
P r o t o c o l < G S M >
S e t A P N
S e t M o d e m T y p e
S e t U s e r N a m e
S e t P a s s w o r d
GPIO Conf:
D e v i c e T y p e < R R C R >
Power Control
G r i d C o n t r o l < E n >
E n e r g y M a n a g e r
R R C R C o n f .
R e a c t i v e P w r C o n f .
A c t i v e P w r C o n f .
P h a s e B a l a n c e < D i s >
W a k e u p C o n f .
P ( f )
A d v a n c e d
L o a d D e f a u l t s

Power control options are detailed in the Power Control Application Note , available on
the SolarEdge website at http://www.solaredge.us/files/pdfs/application_note_power_control_
configuration.pdf.
The Grid Control option may be disabled. Enabling it opens additional
options in the menu.
The Energy Manager option is used for setting power export limitation,
as described in the Export Limitation Application Note , available on the
SolarEdge website at https://www.solaredge.com/sites/default/files/export_
limitation_application_note_NA.pdf.

For P(Q) diagram refer to
https://www.solaredge.com/sites/default/files/application_note_p_q_diagram_of_
se_inverters_en_and_na.pdf
(1)
When using the SolarEdge GSM products this menu is unavailable.
-Three Phase System Installation Guide MAN-01-00002-4.3
70 Inverter Configuration – Setup Mode
