Installation Guide

1. Turn the inverter ON/OFF switch to OFF.
2.
Press and hold down the LCD light button until the following message is displayed:
K e e p h o l d i n g b u t t o n
f o r p a i r i n g , r e l e a s e
t o e n t e r m e n u . . .
R e m a i n i n g :    3 s e c
Releasing the button displays the following menu:
O p t i m i z e r p a i r i n g
L a n g u a g e < e n g >
C o m m u n i c a t i o n
M a i n t e n a n c e
I n f o r m a t i o n
E x i t
3. Short-press (one second) to scroll down to the next menu option, and long-press
(three seconds) to select the item. You can use the Exit option in these menus to
move up one menu level or to exit the Setup mode from the main menu.
The following shows a hierarchical tree of the menu options that appear when using
the LCD light button:
Main menu:
O p t i m i z e r p a i r i n g
L a n g u a g e < e n g >
C o m m u n i c a t i o n
M a i n t e n a n c e
I n f o r m a t i o n
E x i t
Language:
E n g l i s h
G e r m a n
S p a n i s h
F r e n c h
I t a l i a n
E x i t
Communication
(1)
:
(1)
If Wi-Fi is connected, the ZigBee Conf menu is not displayed, and vice versa.
