Installation Guide

C o u n t r y < U S A + >
L a n g u a g e < E n g >
C o m m u n i c a t i o n
P o w e r C o n t r o l
D i s p l a y
M a i n t e n a n c e
I n f o r m a t i o n
The inverter is now in Setup mode and all its LEDs are lit. The inverter automatically exits
Setup mode if no buttons are pressed for more than 2 minutes.

The following shows a hierarchical tree of the menu options, which are described in
Configuration Menu Options on page 66. Actual menus may vary from shown
depending on the firmware version of the inverter and on the country.

Main menu:
C o u n t r y < U S A + >
L a n g u a g e < E n g >
C o m m u n i c a t i o n
P o w e r C o n t r o l
D i s p l a y
M a i n t e n a n c e
I n f o r m a t i o n
Country:
U S A +
Language:
E n g l i s h
G e r m a n
S p a n i s h
F r e n c h
I t a l i a n
Communication:
S e r v e r < L A N >
L A N C o n f
R S 4 8 5 – 1 C o n f < S >
Z i g B e e C o n f < S >
C e l l u l a r C o n f
G P I O C o n f < M T R >
