Fasten the bracket using a standard bolt.

Verify that the bracket is firmly attached to the mounting surface.

Figure 16: Safety Switch bracket

9. Insert the two supplied screws through the outer heat sink fin on both sides of the

inverter and into the bracket (see

Figure 15

). Tighten the screws with a torque of 4.0

N*m / 2.9 lb.*ft.

Chapter 3: Installing the Inverter 41

Three Phase System Installation Guide MAN-01-00002-4.3
