Chapter 3: Installing the Inverter

Install the inverter either before or after the modules and power optimizers have been

installed.

NOTE

Use only copper conductors rated for a minimum of 90°C/ 194°F.

For the SE10KUS, SE20KUS, SE33.3KUS three phase inverters where

opposite polarity DC conductors are routed in the same conduit, 1000V

rated cables must be used.

Inverter Package Contents

One inverter with Safety Switch

One mounting bracket

Two Allen screws for fastening the inverter to the mounting bracket

Quick Installation guide (with activation card and instructions)

Optional (for wireless communication to monitoring platform) - RF antenna and

mounting bracket

AC ferrite bead kit

Identifying the Inverter

Refer to the sticker on the inverter that specifies its Serial Number and its Electrical

Ratings. Provide the serial number when contacting SolarEdge support. The serial

number is also required when opening a new site in the monitoring platform.

Inverter Interfaces

The following figure shows the inverter connectors and components, located at the

bottom of the inverter.
