When installing modules in a confined space, for example, if installing Building-

integrated photovoltaic (BIPV) modules, ventilation measures may be needed to

ensure the power optimizers are not be exposed to temperatures outside their

specifications.

NOTE

The images contained herein are for illustrative purposes only and may vary

depending on product models.

-Three Phase System Installation Guide MAN-01-00002-4.3

24 Installation Guidelines
