- Technical Specifications - Single Phase Inverters (North America)
- Technical Specifications - Three Phase Inverters (North America)
SE9KUS SE10KUS SE14.4KUS SE20KUS SE30KUS SE33.3KUS Units
ADDITIONAL FEATURES
Supported communication
interfaces
RS485, Ethernet, ZigBee(optional)
Rapid Shutdown – NEC 2014 and
2017 690.12
Automatic Rapid Shutdown upon ACgrid disconnect
(1)
RS485 Surge Protection Supplied with the inverter
Smart Energy Management Export Limitation
STANDARD COMPLIANCE
Safety UL1741, UL1741 SA, UL1699B, CSA 22.2, Canadian AFCIaccording to T.I.L. M-07
Grid connection standards IEEE1547, Rule 21, Rule 14 (HI)
Emissions FCC part15 class B
RoHS Yes
INSTALLATION SPECIFICATIONS
AC output conduit size / AWG
range
3/4”
minimum /
12-6 AWG
3/4”
minimum /
12-6 AWG
3/4”
minimum /
8-4 AWG
3/4”
minimum /
12-6 AWG
3/4”
minimum /
8-4 AWG
3/4”
minimum /
8-4 AWG
DC input conduit size / # of
inputs/ AWG range
3/4” minimum / 12-6 AWG
Number of DC inputs 2 pairs
3 pairs (with
fuses on plus
& minus)
(2)
2 pairs
3 pairs(with
fuses on plus
& minus)
1
3 pairs(with
fuses on plus
& minus)
1
(1)
P/N SE9K-US0xxxxxx has Manual Rapid Shutdown for NEC2014 compliance (NEC 2017 compliance with outdoor installation)
(2)
Field replacement kit for 1 pair of inputs P/N: DCD-3PH-1TBK. Field replacement kit for 3 pairs of fuses and holders P/N: DCD-6PHK-S1.
