 SE9KUS SE10KUS SE14.4KUS SE20KUS SE30KUS SE33.3KUS Units

Max. back-feed current 0 A

Power factor range 1 (adjustable from -0.8 to +0.8) 

GFDI threshold 1 A

Total harmonic distortion < 3 %

Utility monitoring, islanding

protection, country configurable

set points

Yes 

INPUT

Maximum DC power 12150 13500 19400 27000 40500 45000 W

Transformer-less, ungrounded Yes 

Maximum input voltage DC to

Gnd

250 490 300 490 490 490 Vdc

Maximum input voltage DC+ to

DC-

500 980 600 980 980 980 Vdc

Nominal input voltage DC to Gnd 200 420 200 420 420 420 Vdc

Nominal input voltage DC+ to

DC-

400 840 400 840 840 840 Vdc

Maximum input current 26.5 13.5 38 26.5 39 40 Adc

Maximum short circuit current  45 Adc

Reverse-polarity protection Yes 

Ground-fault isolation detection

1 MΩ

Sensitivity

1 MΩ

Sensitivity

350 kΩ

Sensitivity

(1)

1 MΩ

Sensitivity

350 kΩ

Sensitivity

350 kΩ

Sensitivity



(1)

Where permitted by local regulations
