 SE3000A-US SE3800A-US SE5000A-US SE6000A-US SE7600A-US SE10000A-US SE11400A-US Units

Inrush current AC

(Peak/ Duration)

2.8/20 3.3/20

Aac (rms) /

Max. output

overcurrent protection

40  60 A

Power factor range 1 (adjustable from -0.85 to +0.85) 

GFDI threshold 1 A

Total harmonic

distortion

<3% 

Utility monitoring,

islanding protection,

country configurable

thresholds

Yes 

INPUT

Maximum DC power

(Module STC)

4050 5100 6750 8100 10250 13500 15350 W

Transformer-less,

ungrounded

Yes 

Maximum input voltage 500 Vdc

Nominal DC input

voltage

325 @ 208V / 350 @ 240V 

Maximum input current

(1)

9.5 13

16.5 @ 208V

15.5 @ 240V

18 23

33 @ 208V

30.5 @ 240V

34.5 Adc

(1)

A higher current source may be used; the inverter will limit its input current to the values stated.

SolarEdge-Three Phase System Installation Guide MAN-01-00002-4.3

115
