Technical Specifications - Single Phase Inverters (North America)
SE3000A-US SE3800A-US SE5000A-US SE6000A-US SE7600A-US SE10000A-US SE11400A-US Units
OUTPUT
Nominal AC power
output
3000 3800 5000 6000 7600
9980 @ 208V
10000 @
240V
11400 VA
Maximum AC power
output
3300 4150
5400 @ 208
5450 @ 240
6000 8350
10800 @
208V 10950
@ 240V
12000 VA
AC output voltage
min.-nom.-max.
(1)
183-208-229 Vac
- - + - - + -
AC output voltage
min.-nom.-max.
1
211-240-264 Vac
+ + + + + + +
AC frequency min-
nom-max
1
59.3 – 60 – 60.5 (with HI country setting: 57 – 60 – 60.5) Hz
Max. output fault
current and duration
@208V
N/A N/A 26 / 20 N/A N/A 48 / 20 N/A A / ms
Max. output fault
current and duration
@240V
14 / 20 17.5 / 20 23 / 20 27.5 / 20 40 / 20 42 / 20 48 / 20 A / ms
Max. continuous
output current
12.5 16
24 @208V
21 @240V
25 32
48 @ 208V
42@ 240V
47.5 A
(1)
For other regional settings, please contact SolarEdge support.
SolarEdge-Three Phase System Installation Guide MAN-01-00002-4.3
114
