Installation Guide

S e r v e r < L A N >
L A N C o n f
R S 4 8 5 – 1 C o n f < S >
Z i g B e e C o n f < S >
W i - F i C o n f < N / A >
G P I O C o n f < M T R >
R S 2 3 2 C o n f
C e l l u l a r C o n f
E x i t
Information:
V e r s i o n s
E r r o r L o g
W a r n i n g l o g
H a r d w a r e I D s
E x i t
Maintenance:
D a t e a n d T i m e
R e s e t C o u n t e r s
F a c t o r y R e s e t
S W U p g r a d e - S D C a r d
A F C I  < D i s >
M a n u a l A F C I  T e s t
D i a g n o s t i c s
S t a n d b y M o d e
O p t i m i z e r C o n f .
G r i d P r o t e c t i o n
B o a r d R e p l a c e m e n t
E x i t
The options presented in these menus are described in the next section.
Configuration Menu Options
This section describes how to use the LCD menus for configuring the inverter.
Configuration is only available when the inverter ON/OFF switch is OFF. Use either the
internal LCD user buttons or the external LCD light button to move between and select
menu options.
Country and Grid
Configuring the country and grid is available using the internal user buttons only.
1.
Select the Country option to specify the country or region in which the inverter is
installed and the grid to which it is connected. This parameter may arrive pre-
configured. If so, verify that it is set to the proper country or region.
-Three Phase System Installation Guide MAN-01-00002-4.3
66 Inverter Configuration – Setup Mode
