Installation Guide

 SE3000A-US SE3800A-US SE5000A-US SE6000A-US SE7600A-US SE10000A-US SE11400A-US Units
Dimensions (H x W x D)
with Safety Switch
30.5 x 12.5 x 7.2 /
775 x 315 x 184
30.5 x 12.5 x 10.5 /
775 x 315 x 260
in/mm
Weight 44.7 / 20.2 47.7/21.7 82.1 / 37.5 lb/kg
Weight with Safety
Switch
51.2/ 23.2 54.7/24.7 88 .4 / 40.1 lb/kg
Cooling Natural Convection
Natural
convection
and internal
fan (user
replaceable)
Fans (user replaceable) 
Noise (typical) < 25 < 50 dBA
Minimum and
maximum operating
temperature range
(1)
-13 to +140 / -25 to +60 (-40 to +60 version available
(2)
)
˚F/˚C
Storage temperature
range
-13 to +140/ -25 to +60 ˚F/˚C
Protection rating NEMA 3R 
Maximum altitude 6562 / 2000 ft / m
Operating humidity –
non condensing
< 95 %
Recommended OCPD size per grid (you may use a larger size than that recommended but never above 40A):
(1)
SolarEdge’s 5kW and 6kW inverters operate at full power and full currents up to a temperature of 120°F/50°C. The inverters may be used above this temperature with reduced
ratings. For more information, refer to http://www.solaredge.com/files/pdfs/se-temperature-derating-note-na.pdf.
(2)
-40 version P/N: SExxxxA-US000NNU4 (for SE76000 inverter: SE7600A-US002NNU4)
SolarEdge-Three Phase System Installation Guide MAN-01-00002-4.3
118 
