Table 1: Circuit Breaker Criteria

Inverter

Max. Continuous Output Current

(per Phase)

Recommended Circuit Breaker

SE12.5K 20A 25A

SE14.4KUS 40A 50A

SE15K 23A 32A

SE16K 25.5A 32A

SE17K 26A 32A

SE25K 38A 50A

SE27.6K 40A 50A

SE30K 36.5A 50A

SE33.3K 40A 50A

SE43.2KUS 120A 150A

SE50K 76A 100A

SE55K 80A 100A

SE66.6K 80A 100A

SE66.6KUS 80A 100A

SE75K 120A 150A

SE82.8K 120A 150A

SE100K 120A 150A

SE100KUS 120A 150A

Appendix E: Determining the Circuit Breaker Size 113

Three Phase System Installation Guide MAN-01-00002-4.3
