Operator Manual AB62 SERIAL NO. 1266 to Current WARNING All personnel shall carefully read, understand and follow all safety rules, operating instructions, and the Scaffold Industry Association’s MANUAL OF RESPONSIBILITIES of ANSI A92.6-1999 before performing maintenance on or operating any UpRight Aerial Work Platform.
AB62 Aerial Work Platform Serial Numbers 1266 - Current When contacting UpRight for service or parts information, be sure to include the MODEL and SERIAL NUMBERS from the equipment nameplate. Should the nameplate be missing, the SERIAL NUMBER is also stamped on top of the chassis above the front axle pivot. UpRight, Inc. 801 South Pine Street Madera, California 93637 TEL: 559-662-3900 FAX: 559-673-6184 PARTS: 1-888-UR-PARTS PARTS FAX: 1-800-669-9884 Call Toll Free in U.S.A.
OPERATOR MANUAL WARNING All personnel shall carefully read, understand and follow all safety rules and operating instructions before operating or performing maintenance on any UpRight aerial work platform. Safety Rules Electrocution Hazard NEVER operate the machine within ten (10) feet of power lines. THIS MACHINE IS NOT INSULATED.
C ONTENTS Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Special Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 All Models:. . . . . . . . .
Introduction I NTRODUCTION This manual covers the operation of the AB62 Articulated Boom. This manual must be stored on the machine at all times. G ENERAL D ESCRIPTION Figure 2: AB62 Work Platform 1. Platform • The platform has a non-slip aluminum floor, guardrails with midrail, toeboards, and an entrance gate at the rear of the platform. 4 5 2. Platform Controls • The Platform Controller is located at the front of the platform cage.
Controls and Indicators C ONTROLS AND I NDICATORS Figure 3: Controls and Indicators 1. Hour Meter Diesel Model Chassis Controls 2. Water Temp. 3. Oil Pressure 4. Breaker 3 2 1 4 5 5. Diesel - Glow Plug Light Gasoline/LPG - Plugged 7 6. Function Enable 8 6 9 11 10 12 7. Engine Start 8. Key Switch 9. Emergency Stop 10. Riser 11. Boom Extend/Retract 12. Jib Raise/Lower 13. Boom Raise/Lower 13 17 14. Turret Rotate 15. Platform Rotate 16. Platform Level 17. Function Speed HI/LOW 14 18.
Pre-Operation Safety Inspection P RE -O PERATION S AFETY I NSPECTION VISUAL INSPECTION NOTE: Carefully read, understand and follow all safety rules, labels, and operating instructions; then perform the following steps each day before use. Perform a complete visual inspection of the entire unit prior to operating. Check the following areas for discrepancies: 1. Open the covers and check hydraulic components and hoses for damage or leaks. 2.
Pre-Operation Safety Inspection SYSTEM FUNCTION INSPECTION 1. Move the machine to a firm level surface with room to fully elevate and extend the platform. 2. Before performing the following tests, check the area around the machine and overhead for obstructions, holes, drop-offs, and debris. 3. Ensure that the locking pins are retracted (refer to Figure 4 on page 5). C A U T I O N Attempting to rotate the turret with locking pins engaged may cause damage to the machine. 4.
Operation O PERATION Before operating the work platform ensure that: • Pre-operation and safety inspection has been completed, and any discrepancies have been corrected. • The operator has been thoroughly trained on the operation of the machine. • The work area is clear of all obstructions, holes, drop-offs, or persons in the route of travel. • The surface is capable of supporting wheel loads.
Operation DRIVING WITH BOOM LOWERED 1. Turn the chassis key switch to PLATFORM, and turn on (turn clockwise) the chassis Emergency Stop switch. 2. Mount the platform, close and latch the gate. 3. Attach an approved fall restraint to the designated platform anchorage point. Attach only one fall restraint to each point. 4. Start the engine. 5.
Operation STEERING 1. Depress the foot switch. 2. Push the steering rocker switch to the left to turn left. 3. Push the steering rocker switch to the right to turn right. NOTE: Steering is not self-centering. Wheels must be returned to the straight ahead position by operating the steering switch. NOTE: When the boom is rotated to the front of the chassis (steering wheels aft), directions of travel and steering will be reversed.
Operation UPPER CONTROL OPERATION 1. Turn the chassis key switch to the left (Platform). 2. Turn ON the platform ignition switch. LEVELING THE PLATFORM ! W A R N I N G ! DO NOT operate the machine if the platform does not maintain level when elevated. NOTE: Platform leveling should be done only to calibrate the automatic leveling system. 1. Set the Function Speed control dial to the desired setting. Rotate the dial clockwise to increase speed, counterclockwise to decrease.
Operation EXTENDING THE UPPER BOOM 1. Set the Function Speed control dial to the desired setting. Rotate the dial clockwise to increase speed, counterclockwise to decrease. If you are not sure what speed to use, start out slow; the speed can be varied while operating the function. 2. While depressing the foot switch, push the Boom Extend control lever rearward to extend the boom, forward to retract the boom. Release the control lever to stop extending/retracting. ELEVATING THE JIB 1.
Emergency Operation E MERGENCY O PERATION In the event of a powered function failure, the elevating assembly may be lowered by using the Auxiliary Power Unit. Hold in the Auxiliary Power button and operate the Lowering Controls as normal. ! W A R N I N G ! NEVER climb down the elevating assembly. If controls do not respond, ask someone on the ground to lower the boom manually. A FTER U SE E ACH D AY 1. Ensure that the platform is fully lowered. 2.
Transportation TRANSPORTATION BY CRANE 1. Ensure that the boom is fully lowered and retracted. 2. Ensure that the locking pins are engaged (refer to Figure 4 on page 5). 3. Attach straps to the Chassis Lifting lugs only. Ensure that the straps are adjusted properly to keep the unit level when lifting. B Y TR U C K O R TR A I L E R 1. Ensure that the boom is fully lowered and retracted. 2. Ensure that the locking pins are engaged (refer to Figure 4 on page 5). DRIVE ONTO TRANSPORT VEHICLE 1.
Daily Maintenance D AILY M AINTENANCE FUELING Stop the engine and turn off the key switch before re-fueling. Figure 9: Fuel Tank GASOLINE 1. Open the left turret cover, then open the fill cap. 2. Fill to capacity with unleaded gasoline only. Fuel Cap • Fuel tank full capacity is 159 liters (42 US gallons). 3. Install the cap. DIESEL 1. Open the left turret cover, then open the fill cap. 2. Fill to capacity with diesel motor fuel only, grade #1-D or #2-D.
Daily Maintenance BATTER Y MAINTENANCE ! W A R N I N G ! Hazard of explosive gas mixture. Keep sparks, flame, and smoking material away from battery. Always wear safety glasses when working with batteries. Battery fluid is highly corrosive. Thoroughly rinse away any spilled fluid with clean water. Always replace batteries with UpRight batteries or manufacturer approved replacements weighing >28 kg (62 lbs.) each. Check battery fluid level daily. If the electrolyte level is lower than 10 mm (3/8 in.
Inspection and Maintenance schedule I NSPECTION AND M AINTENANCE SCHEDULE The complete inspection consists of visual and operational checks, together with all necessary minor adjustments to assure proper performance. Daily inspection will prevent abnormal wear and prolong the life of all systems. A thorough inspection and maintenance shall be performed by personnel who are trained and familiar with mechanical and electrical procedures at regular intervals.
Inspection and Maintenance schedule DAILY PREVENTATIVE MAINTENANCE CHECK LIST MAINTENANCE TABLE KEY PREVENTATIVE MAINTENANCE REPORT Y = Yes/Acceptable Date: _______________________________________ N = No/Not Acceptable Owner: _____________________________________ R = Repaired/Acceptable Model No: ___________________________________ Serial No: ___________________________________ Serviced By: _________________________________ COMPONENT Battery Engine Oil and Filter INSPECTION OR SERVICES Check ele
Safety Labels S AFETY L ABELS Proper label installation is required. All of these labels shall be present and in good condition before operating the work platform. Be sure to read, understand and follow these labels BEFORE operating the work platform.
Safety Labels Figure 12: Safety Labels Locations 19 8 Both Sides 26 9 23 37 41 Both Sides Both Sides 38 Both Sides 11 or 12 10 40 Both Sides 24 Front & Rear 23 30 Front & Rear 29 35 36 32 7 5 6 34 13 42 Both Sides (Option) 33 38 Both Sides 40 Both Sides 23 32 9 8 37 21 1 35 24 Front & Rear 30 Front & Rear 104044-001 AB62 Work Platform - Operator Manual 32 36 Page 19
Specifications S PECIFICATIONS Specifications are subject to change without notice. Hot weather or heavy use may affect performance. ITEM Specification Reach Envelope Diagram Height Working Height 20,7 m [68 ft.] Max. Platform Height 18,9 m [62 ft.] Platform step in Height Up and Over Height Drivable Height Horizontal Outreach Turret Rotation Platform Rotation 343 mm [13.5 in.] 9,1m [30 ft.] 18,9 m [62 ft.] 10,7 m [35 ft.] 360° Continuous 180° Tail Swing 0 Jib Length 1,9 m [6ft. 4 in.
