Use and Care Manual

GB - 8
For extended storage, clean unit thoroughly.
See engine manual for proper storage.
Use only attachments or accessories
designed for your unit.
Check components frequently. If worn or
damaged, replace with manufacturer’s
recommended parts.
PACKAGE CONTENTS
ASSEMBLY
Tools Required:
• Pliers
• Open-end wrenches: 3/8, 7/16, 1/2,
9/16 in. and/or adjustable wrench
• Tire gauge
Unfold Handlebar (Figure 4)
1. Remove the lower and loosen the upper
hardware on the handlebar assembly.
2. Rotate the handlebars into operating
position.
NOTE: Be careful not to damage the cable
spring hooks when rotating handlebars
upward.
3. Install and tighten the hardware on the
handlebar assembly.
ASSEMBLY
WARNING: AVOID INJURY. Read
and understand the entire Safety
section before proceeding.
WARNING: Dropping or tipping
over boxed unit could result in
personal injury or damage to unit.
Figure 3
1. Discharge
Chute
2. Chute Crank
3. Sno-Tek™
Unit
4. Literature
Pack with
Extra Shear
Bolts
3
2
1
4
Figure 4
1. Lower
Handlebar
2. Hardware
3. Upper
Handlebar
OS7020
2
3
1
