SPECIFICATIONS
Model Number 939400 939401
Description Sno-Tek™ 22 Sno-Tek™ 20
Engine
Engine Model LCT Storm Force
Gross Torque* - ft-lbs (N-m) 9.5 (12.9)
*Engine output stated in gross torque per SAE J1940 as rated by engine manufacturer
Displacement - in. (cc) 12.7 (208)
High Idle - RPM (min) 3600 ± 50
Start Recoil
Fuel Tank Capacity - qt (Liters) 3.8 (3.6)
Chute
Chute Rotation Angle 205°
Rotation Control 2.5X Quick Turn
Deflector Control Manual
Auger
Snow Clearing Width - in. (cm) 22.0 (55.9) 20.0 (50.8)
Gear Case Aluminum
Auger Diameter - in. (cm) 11.0 (27.9)
Impeller
Impeller Diameter - in. (cm) 12.0 (30.5)
Impeller Speed (RPM) 1071
Impeller Tip Speed - ft/min (m/min) 3365 (1026)
Drive
Blower Drive 4L Belt
Drive System Clutching Wet Sump Gearbox
Speeds 1 Forward
Axle Control Solid Locked
Pneumatic Tires - in. (cm) 13 x 4-6 10 x 4-4
Size and Weight
Length - in. (cm) 51.1 (129.8) 51.3 (130.2)
Height - in. (cm) 44.7 (113.4) 43.1 (109.5)
Width - in. (cm) 24.4 (62.0) 22.4 (56.8)
Weight - lbs (Kg) 151 (68.5) 130 (58.9)
