14.1.1 Scan Module Pairing
For detailed information on the use and pairing of the Scan Module, see Scan Module Operation
on page 54.
14.1.2 Paring the M2 Scope/Meter
NOTE:
i The M2 Scope/Meter is optional equipment for some Diagnostic Tools and may not be included
with your Diagnostic Tool kit. For detailed operation instructions, see the M2 Scope/Meter
instructions supplied with your M2 and/or Diagnostic Tool. M2 operation instructions can also be
found on our website, see the Contact Information section in the front of this manual for website
address information.
Pairing is the wireless connection (identification) process used to connect the M2 Scope/Meter to
your Diagnostic Tool. The M2 Scope/Meter needs to be paired (connected) to the Diagnostic Tool
for remote operation.
Hardware
Icon
Background
Color
Condition Action
Scan Module
Red Not Paired
Pair the Scan Module to the Diagnostic Tool.
See Pairing The Scan Module on page 55 for
instructions.
Grey
Paired, but Not
Communicating
You may have moved out of range. Move the
Diagnostic Tool closer to the Scan Module to
reestablish communications. If connectivity is
not restored, perform the Recovery Procedure
on page 60.
Green
Paired and
Communicating
Hardware status is good and Bluetooth should
be functional. Verify that the green Bluetooth
LED on the front of the Scan Module is flashing.
If there is no connectivity, perform the Recovery
Procedure on page 60.
M2 Scope/Meter
Red Not Paired
Pair the M2 to the Diagnostic Tool. See Paring
the M2 Scope/Meter on page 141 for
instructions.
Grey
Paired, but Not
Communicating
You may have moved out of range. Move the
M2 closer to the Diagnostic Tool to reestablish
communications.
Green
Paired, and
Communicating
Hardware status is good and Bluetooth is
communicating.
