Installation Manual

WWW.SMITTYBILT.COM
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Installation Instructions
Replacement Top (Part # 9085235)
2010 and Up Unlimited (4 Door)
Replacement Top (Part # 9075235)
2010 and Up JK (2 Door)
(Fig 18) (Fig 19)
Step 12: Clamp the front windshield header down onto windshield frame hooks completely. (Fig 20)
Step 13: Now secure the flap to the middle bow, again using the hardware previously removed. (Fig 21)
(4-Door only)
Step 14: Make sure the rear of the top is centered over the rear bow. Then secure the flaps on the top to the
bow using the previously removed hardware. (Fig 22)
(Fig 20) (Fig 21)
