Installation Instructions
Replacement Top (Part # 9085235)
2010 and Up Unlimited (4 Door)
Replacement Top (Part # 9075235)
2010 and Up JK (2 Door)
Step 8: Install the foam strip on bottom front corners. (Fig 14)
Step 9: Install the foam pad on each edge of the bottom of the header (Fig 15) Note: there is a driver and a
passenger side.
(Fig 14) (Fig 15)
Step 10: Raise the header back down on the windshield frame. (Do not clamp) Drape the top back
completely over the bow assembly. (Fig 16) Note: make sure the pivot assembly on the top on the door
surrounds is locked/latched into place. (Fig 17)
(Fig 16) (Fig 17)
Step 11: Attach the cable spring end to the bracket on the bow, crimp to secure. (Fig 18, 19)
