NOMENCLATURE

Smith & Wesson firearms are reliable and safe to use when the

firearm safety rules are followed. There are a number of internal

safety mechanisms within the lockwork of the firearm which

ensure that the firearm will not discharge unless the trigger of the

firearm is pulled. That is one reason why it is important to never

modify or alter your firearm. Before you use your firearm, you

should be fully familiar with its operation.

Here is a list of basic firearms terminology.

AMMUNITION - CENTERFIRE - Ammunition which contains the

primer in the center of the base of the case. Among the most

common centerfire firearm cartridges are the .32, .38 Special,

.380, 9mm, .357 Magnum®, .40 S&W®, .45 ACP, .44 Magnum

and 5.56mm.

AMMUNITION - RIMFIRE - Ammunition which contains the

primer material in the rim. Among the most common rimfire

firearm cartridges are the .22 Short, .22 Long, .22 LR, and

.22 Magnum.

BOLT - The mechanism that houses the firing pin.

BOL

T CATCH

- The lever that, when depressed, releases the

bolt carrier assembly to the forward position.

CALIBER - The diameter of a bullet, designated in hundredths or

thousandths of an inch (.357) or in millimeters (9mm).

CHARGING HANDLE - This cocks the firearm when preparing to

fire or clean.

FLASH SUPPRESSOR - This reduces the amount of flash from

the muzzle when the weapon is fired.

HAND GUARD - This is a protective shield that covers the gas

tube and the barrel keeping your hand from the hot barrel.

LOWER RECEIVER - Lower part of the rifle containing the

receiver, trigger and associated parts.

RIFLE - A weapon that can be fired from the shoulder.

SAFETY SELECTOR LEVER - This feature changes the trigger

between the safe mode and the firing modes.

UPPER RECEIVER - The part of the receiver containing the bar-

rel, sights, bolt and associated parts.

The operation of your firearm will be explained in greater detail in

the pages that follow, as well as a greater description of key

component parts.
