WARNING: NEVER DISASSEMBLE YOUR FIREARM
BEYOND THE FIELD STRIPPING PROCESS OUTLINED
IN THIS MANUAL. NEVER MANIPULATE ANY INTER-
NAL COMPONENTS BEYOND WHAT YOU ARE SPECIFICALLY
INSTRUCTED TO DO IN THIS MANUAL SINCE THIS MAY AFFECT
THE RELIABILITY, FUNCTIONING AND SAFETY OF YOUR
FIREARM.
WARNING: DO NOT ALTER, MODIFY OR REPLACE
ANY OF THE PARTS OF YOUR FIREARM UNLESS THIS
WORK IS PERFORMED BY A QUALIFIED GUNSMITH
USING GENUINE SMITH & WESSON PARTS. IF YOU DO OTH-
ERWISE, IMPROPER FUNCTIONING MAY OCCUR AND SERI-
OUS INJURY MAY RESULT.
22
FIELD STRIPPING DISASSEMBLY CONT’D.
BUFFER AND SPRING FIELD STRIPPING
WARNING: ALWAYS ENSURE THAT THE RIFLE IS
UNLOADED BEFORE ANY PROCEDURE IS
ATTEMPTED.
• Push in buffer (at the rear of the receiver/front of the stock)
slightly and depress buffer retainer to release the buffer.
(Figure 33)
• Remove buffer and spring from the buffer tube. (Figure 34)
FIGURE 33
FIGURE 34
