Specifications

Product Specifications
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE802.3ab 1000BASE-T
IEEE802.3x full duplex flow control
Pre-IEEE 802.3az
IEEE 802.1p QoS
Interface 5/8* 10/100/1000 Mbps RJ-45 ports
Network
Data Rate
10/100/1000 Mbps Auto-negotiation
Transmission Mode
10/100Mbps: Full-duplex, Half-duplex
1000Mbps: Full-duplex
Switching Capacity
5 Port:10Gbps
8 Port:16Gbps
Switching Forwarding
Rate
5 Port: 7.4Mpps
8 Port: 11.9Mpps
Buffer Memory 5/8 Port :128K bytes
MAC Address Table 5/8 Port :8K
Jumbo Frame 5/8 Port :9K bytes
Temperature Operating: 0°C ~ 40°C (32°F ~104°F)
Humidity 10% to 90% non-condensing
LED Indications
System: Power
Ports: Link/Act
Power Supply 5/8 Port :External power adapter 5V/1A
Dimensions
5 Port :121.0*75*26mm(4.84*3.0*1.0 in)
8 Port :154.5*85*26mm(6.18*3.4*1.0 in)
Weight
5 Port : 253g(0.12lbs)
8 Port : 355g(0.16lbs)
Emission FCC, CE, VCCI Class A
