Wireless Access Point Data Sheet
SMC is a registered trademark of SMC Networks, Inc. All other brand and product names are trademarks of their respective holders.
©2000 SMC Networks, Inc. Printed in the USA. 07/2000
SMC Networks
6 Hughes
Irvine, CA 92618
949.707.2400
949.707.2460 fax
1-800-SMC-4-YOU
www.smc.com
Specifications
SMC2652W
Data Rates
• 11 Mbps,5.5 Mbps,2 Mbps,1 Mbps/Channel
Maximum Channels
• US & Canada:11
• Europe:13
• Japan:14
Maximum Clients
• 128
Operating Range
• Up to 1500’
Cell Separation
200’ between Access Points
Network Configuration
• Standalone wireless infrastructure
• Wired
Radio Signal Type
Direct Sequence Spread Spectrum (DSSS)
Encryption
64- or 128-bit keys
Configuration and Management
Web -based utilities
Operating Frequency
• US & Canada:2.400-2.4835 Ghz
• Europe & Japan:2.400-2.497 Ghz
Sensitivity
-80 dBm (typical) - 1,2,5.5 Mbps
-76 dBm - 11 Mbps
Modulation
• QPSK
• BPSK
• CCK
Output Power
+13dBm minimum
50 mW maximum
Operating Systems
Windows 95/98,NT,2000
Inband Management
Windows 95/98/NT configuration utility
Outband Management
Console connection to RS232 port
Power Input
100-240 AC,50-60 Hz
Power Output
9 Vdc,1A(power adapter)
Size
• 5.1 x 7.1 x 1.6 in.
• 13 x 18 x 4 cm
Weight
• 0.80 lbs
• 0.365 kg
Operating Temperature
Operating = 0°C to +50°C
Storage = 0°C to +70°C
Humidity
5% to 80% (non-condensing)
Network Connection
• IEEE 802.3 – 10 Mbps via RJ-45 port
• IEEE 802.11b – 11 Mbps via antenna
Antenna
Dipole antenna for indoor applications
LED Indicators
• Power
• Ethernet Link
• Ethernet Activity
• Wireless Link
• Wireless Activity
EMC/Safety Compliances
• CE Mark
• EN55022 Class B
• EN55024
• IEC 61000 - 4 2/3/4/6/11
Emissions
FCC Class B,ETS 300-328,RCR STD-33
Safety
• CSA/NTRL (CSA 22.2 No.950,UL1950)
• TUV/GS (EN60950)
Vibration/Shock/Drop
IEC 68-2-34/IEC 68-2-27/IEC 68-2-32
Standards
• IEEE 802.3
• IEEE 802.11b
Warranty
Limited lifetime
Product Description
SMC2652W 11 Mbps Wireless LAN,2.4GHz DSSS Wireless Ethernet Access Point
SMC2620W 11 Mbps Wireless Networking Starter Kit (Includes an Access Point
and a Wireless PC Card)
