USER GUIDE 2652W_UK.qxd 5/4/01 11:08 am Page 1 EZ Connect™ Wireless Access Point User Guide SMC2652W V1.
USER GUIDE 2652W_UK.qxd 5/4/01 11:08 am Page 3 Hello and welcome! - NEW TEXT?? Package Checklist: The SMC EZ Connect Network Kit contains everything you need to quickly and easily connect computers in your home or office together to form your own network or extend and improve your existing network. 1 1 1 1 1 The SMC EZ Connect Network Kit continues the SMC Home and Small Office network range and offers the fastest performance out of all of the products.
USER GUIDE 2652W_UK.
USER GUIDE 2652W_UK.qxd 5/4/01 11:08 am Page 7 3. Connect the Ethernet cable - The SC2652W can be wired to a 10Base-T Ethernet network with a network device such as a hub or switch. Connect into the RJ45 connector socket on the back panel with category 3, 4 or 5 UTP Ethernet cable and an RJ45 connector. 4. Connect the power cable - Connect the power adapter cable to the 9V DC power socket on the rear panel. Windows NT/95/98/2000 Installation 1.
USER GUIDE 2652W_UK.qxd 5/4/01 11:08 am Page 9 Encryption: Click Encryption icon for the WEP setting. The information MIB screen displays the categories of information shown above. In the “AP control MIB page”, set the parameters and then double click on “apply” to implement the settings. DS channel - Set the channel number as the operating radio channel. Note: the available channel settings are displayed to the right of the “DS channel” field. Local regulations determine which channels are available.
USER GUIDE 2652W_UK.qxd 5/4/01 11:08 am Page 11 Key entry - This field can be set to “passphrase” or “manual Entry”. Select “Entry”. The “passphrase” means the key elements will be auto generated by the internal algorithym according the string defined in the passphrase field. The “Manual Entry” means the key elements allow/need user key in by manually.
USER GUIDE 2652W_UK.qxd 5/4/01 11:08 am Page 13 EZ Connect Wireless Network Configuration and Planning Infrastructure Wireless LAN SMC’s EZ Connect Wireless Solution supports a stand-alone wireless network configuration, as well as anintegrated configuration with 10 Mbps Ethernet LANs. The SMC2652W can also provide access to a wired LAN for wireless workstations. An integrated wired and wireless LAN is called an Infrastructure configuration.
USER GUIDE 2652W_UK.qxd 5/4/01 11:08 am Page 15 Setting the Communication Domain Trouble shooting: Stationary Wireless PCs The Basic Service Set (BSS) is the communication domain for each SMC2652W access point. For wireless PCs that do not need to support roaming, set the domain identifier (SSID) for the wireless card to the BSS ID of the access point you want to connect to. Check with your administrator for the BSS ID of the SMC2652W access point he wants you to connect to.
USER GUIDE 2652W_UK.qxd 5/4/01 11:08 am Page 17 The function changes to the next in sequence every time the push button is pressed. The pattern repaeats (Function: 0,1,2,3,0,1,2,3,0,....) as the push button is pressed repeatedly. Model Maximum channels Maximum clients Operating range SMC2652W ETSI: 13 128 Cell seperation 30M between access points (for roaming clients) Data Rate 1, 2, 5.5, 11Mbps per channel Network configuration Lan to access point to wireless card, access point to wireless card.
USER GUIDE 2652W_UK.qxd 5/4/01 11:08 am Page 19 Copyright - New Text ?? Information furnished by SMC brand is believed to be accurate and reliable.However,no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use.No license is granted by implication or otherwise under any patent or patents by SMC.SMC reserves the right to change specifications at any time without notice. Trademarks SMC is a registered trademark.
