1 INTRODUCTION
OVERVIEW
SMC Network’s SMCFS2601P 24-Port 10/100 +2G Combo Unmanaged PoE
Switch provides seamless network connections, integrating 1000 Mbps Gigabit
Ethernet, 100 Mbps Fast Ethernet, and 10 Mbps Ethernet network capabilities.
The PoE ports can automatically detect and supply power to IEEE 802.3af/at-
compliant Powered Devices (PDs). The electrical power is transmitted along with
data in one single cable, allowing you to expand your network to where there
are no power lines or outlets, to where you need to locate devices such as APs,
IP cameras or IP phones, etc.
The SMCFS2601P is easy to install and requires no configuration. With its
desktop design, outstanding performance and quality, the 24-Port 10/100 + 2G
Combo PoE switch is an ideal choice for expanding your home or office network.
FEATURES
◆ Complies with IEEE 802.3, IEEE 802.3u, and IEEE 802.3ab standards
◆ 24 10/100 Mbps auto-negatiating RJ-45 ports
◆ Two 10/100/1000 (RJ-45+SFP) combo ports
◆ Support for PoE on ports 1-24
◆ Supports 30 W of power on six ports, or 15.4 W on 12 ports
◆ Ports 1-24 can provide up to 30 W PoE power budget; total switch PoE
budget is 180 W
◆ LED indicators for monitoring Power, LNK/ACK, PoE in Use, and 1000 Mbps
◆ Rack-mountable steel case
