EZ ConnectTM g 2.4GHz 802.11g Wireless Ethernet Bridge User Guide From SMC’s EZ line of low-cost workgroup LAN solutions 38 Tesla Irvine, CA 92618 Phone: (949) 679-8000 January 2005 Revision #: R01, F1.
Copyright Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to change specifications at any time without notice. Copyright © 2005 by SMC Networks, Inc.
COMPLIANCES FCC - Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with instructions, may cause harmful interference to radio communications.
COMPLIANCES Industry Canada - Class B Operation is subject to the following two conditions: 1) this device may not cause interference and 2) this device must accept any interference, including interference that may cause undesired operation of the device This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of the Department of Communications.
COMPLIANCES Countries of Operation & Conditions of Use in the European Community This device is intended to be operated in all countries of the European Community. Requirements for indoor vs.
COMPLIANCES Declaration of Conformity in Languages of the European Community English Hereby, SMC Networks, declares that this Radio LAN device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Finnish Valmistaja SMC Networks vakuuttaa täten että Radio LAN device tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
COMPLIANCES Italian Con la presente SMC Networks dichiara che questo Radio LAN device è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
COMPLIANCES Wichtige Sicherheitshinweise (Germany) 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. 4. Die Netzanschlu ßsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein. 5. Das Gerät ist vor Feuchtigkeit zu schützen. 6.
TABLE OF CONTENTS EZ Connect™ 2.4 GHz Wireless Ethernet Bridge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Package Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Hardware Description . . . . . . . . . . . . . . . . . . . . . . . 3 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 LED Indicators . . . . . . . . . . . . . . . .
TABLE OF CONTENTS Web Management . . . . . . . . . . . . . . . . . . . . . . . . .29 Browser Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . Disable Proxy Connection . . . . . . . . . . . . . . . . . . . . . . . Internet Explorer (5.5 or above) in Microsoft Windows . Internet Explorer in Macintosh . . . . . . . . . . . . . . . . . . . . Navigating the Web Browser Interface . . . . . . . . . . . . . . . Making Configuration Changes . . . . . . . . . . . . . . . . . . . System . . . . .
EZ CONNECT™ 2.4 GHZ WIRELESS ETHERNET BRIDGE Introduction SMC’s EZ Connect 2.4 GHz Wireless Ethernet Bridge (SMC2870W) can function as: • an Ethernet adapter, providing a wireless connection via an RJ-45 connection to devices such as Microsoft Xbox and Ethernet ready embedded devices • a standard IEEE 802.
EZ CONNECT™ 2.4 GHZ WIRELESS ETHERNET BRIDGE Package Checklist The EZ Connect 2.4 GHz 802.11g Wireless Ethernet Bridge package includes: • One EZ Connect 2.4 GHz 802.11g Wireless Ethernet Bridge (SMC2870W) • One 5 VDC power adapter • Installation CD containing this User Guide, EZ Installation Wizard, and Utility program • One RJ-45 cable Please register this product and upgrade the product warranty on SMC’s web site at http://www.smc.
HARDWARE DESCRIPTION The Wireless Ethernet Bridge supports 1, 2, 5.5 and 11 Mbps half-duplex connections to Ethernet networks. This device is fully compliant with 2.4 GHz DSSS/OFDM wireless networking as defined in IEEE 802.11b/g. The Wireless Ethernet Bridge is backward compatible with the existing 802.11b WLAN infrastructure. It also can be connected via an RJ-45 connection to devices such as Nintendo GameCube, Microsoft Xbox, Sony PlayStation II, and Ethernet ready embedded devices.
HARDWARE DESCRIPTION Applications EZ Connect wireless products offer a fast, reliable, cost-effective solution for wireless Ethernet client access to the network in applications such as: 4 • Video Game Systems Provides wireless Internet access for users of video game systems such as Nintendo GameCube, Microsoft Xbox and Sony PlayStation II • Remote access to corporate network information Email, file transfer, and terminal emulation • Difficult-to-wire environments Historical or old buildings, asbest
LED INDICATORS LED Indicators The Wireless Ethernet Bridge includes three status LED indicators, as described in the following figure and table. Figure 2. Front Panel LED Status Description Wireless Link TX/RX Flashing (Green) The device is transmitting or receiving data through wireless links. Ethernet Status LINK/ ACT On (Orange) The device has established a valid 10 Mbps Ethernet link. On (Green) The device has established a valid 100 Mbps Ethernet link.
HARDWARE DESCRIPTION System Requirements Before you install the Wireless Ethernet Bridge, be sure you have met the following requirements: 6 • An AC power outlet (100~240 V, 50~60 Hz) • An available RJ-45 (UTP) port on an Ethernet hub or switch • 802.11b/g compliant wireless Ethernet adapters with TCP/IP protocols installed • TCP/IP network protocol installed on each PC that needs to access the Internet • A web browser, such as Microsoft Internet Explorer 5.
HARDWARE INSTALLATION 1. Select the site – Choose a location for your Wireless Ethernet Bridge. Usually, the best location is at the center of your wireless coverage area, if possible within line-of-sight of all wireless devices. 2. Place the Wireless Ethernet Bridge in a position that gives it maximum coverage. Normally, the higher you place the antenna, the better the performance. 3. Position the antennas in the desired positions. For more effective coverage, position the antennas along different axes.
SYSTEM CONFIGURATION The SMC2870W is a Plug-and-Play device. This means that, in most cases, you will not need to configure it. The SMC2870W Wireless Ethernet Bridge includes an SNMP agent that is accessible through an SNMP manager application (Refer to “Using the Configuration Utility” on page 11.) The latest version may be downloaded from the SMC web site specified on the back cover of this manual. The SMC2870W can be configured by a web browser, specifically Internet Explorer 5.5 or above.
EZ INSTALLATION WIZARD To configure your SMC2870W, first verify that your computer has an IP address in the same subnet as the SMC2870W. If you are not familiar with this procedure, see the “Using IPCONFIG” section below. Note: The default IP address of the SMC2870W is 192.168.2.25. 1. Insert the SMC EZ Installation Wizard & Documentation CD into your CD-ROM drive. 2. The EZ Installation Wizard will appear. Click “Configuration Utility” to begin the utility installation and setup process. Using IPCONFIG 1.
UTILITY INSTALLATION AND CONFIGURATION Note: This Configuration Utility is for Windows 98SE, Me, 2000, and XP. After clicking “Configuration Utility,” follow the on-screen instructions to install the utility program.
USING THE CONFIGURATION UTILITY Using the Configuration Utility 1. Click Start/Programs/SMC2870W/SMC2870W Configuration Utility. 2. The program will automatically scan for SMC2870W access points on the network. If you want to subsequently detect all access points on the network, click the Scan button. From the list of detected SMC2870Ws, double-click on the IP address of the unit you wish to configure. A dialogue box will prompt you for the login password.
UTILITY INSTALLATION AND CONFIGURATION Utility Configuration Operation Mode Select the connection mode for SMC2870W and click Next.
UTILITY CONFIGURATION Network Settings The following screen allows you to set up the IP settings of the SMC2870W. Menu Description DHCP Client You can enable the DHCP Client function to automatically get an IP Address, Subnet Mask, and Default Gateway from a DHCP server in your network. (Default: Use Static IP) IP address Set the IP address for SMC2870W as required. (Default: 192.168.2.25) Subnet mask Set the Subnet Mask as required. (Default: 255.255.255.
UTILITY INSTALLATION AND CONFIGURATION Wireless Settings The Wireless Settings page allows you to set up the wireless configurations. Menu Description Wireless Settings 14 Wireless Network Name (SSID) All wireless clients and the wireless access points within a specific ESS (Extended Service Set) must be configured with the same SSID. (Default: SMC) Device Name The name of the wireless access point. (Default: SMC2870W) Channel Set the operating radio channel.
UTILITY CONFIGURATION Security The Security screen provides you with a versatile encryption method to prevent unauthorized access to your wireless network and provide more secure data transmissions. If you are transmitting sensitive data across wireless channels, you should enable Wi-Fi Protected Access (WPA) or Wired Equivalent Privacy (WEP) encryption.
UTILITY INSTALLATION AND CONFIGURATION The security mechanisms that may be employed depend on the level of security required, the network and management resources available, and the software support provided on wireless clients. A summary of wireless security considerations is listed in the following table. Security Client Mechanism Support Implementation Considerations WEP Built-in support on all 802.11b and 802.
UTILITY CONFIGURATION WEP Encryption Type You can choose between standard 64-bit or the more robust 128-bit encryption. To manually configure the keys, select the WEP encryption type option from the drop down menu. For 64-bit encryption enter 5 hexadecimal pairs for each key. For 128-bit encryption enter 13 hexadecimal pairs for each key.
UTILITY INSTALLATION AND CONFIGURATION To generate the keys automatically, enter the Passphrase in the provided field. If you use encryption, configure the same keys used for the Wireless Ethernet Bridge on each of your wireless clients. Note that Wired Equivalent Privacy (WEP) protects data transmitted between wireless nodes, but does not protect any transmissions over your wired network or over the Internet.
UTILITY CONFIGURATION WPA-PSK Encryption Type WPA is a stronger wireless security solution than WEP. It uses a combination of authentication and broadcast/session keys. • Pre-Shared Key/Passphrase If there is no authentication server on your SOHO network, you can issue the Pre-Shared Key to the clients that connect to the Wireless Ethernet Bridge. Be sure to use the same key for the Wireless Ethernet Bridge and the connected clients. Notes: 1. Manual Pre-Shared Key supports up to 64-Hex characters. 2.
UTILITY INSTALLATION AND CONFIGURATION 3. Do not use a key that is long and complex for your clients to type accurately, as you might forget it. 4. A Hex (hexadecimal) digit is a number or letter in the range 0-9 or A-F. WPA-802.1X Encryption Type The Wireless Ethernet Bridge allows you to use 802.1x authentication for an enterprise network environment with a RADIUS server installed. In 802.1x mode, access will be checked against the authentication database stored on the Wireless Ethernet Bridge.
UTILITY CONFIGURATION Setting Information The next screen displays system information. Click Next and Finish to complete the SMC2870W configuration.
UTILITY INSTALLATION AND CONFIGURATION Press OK and reboot the Wireless Ethernet Bridge when prompted to do so.
CONFIGURING YOUR IP ADDRESS Windows 2000 1. Right-click the “Network Places” icon on your desktop and click “Properties.
CONFIGURING YOUR IP ADDRESS 2. Right-click your Local Area Connection and click “Properties.
WINDOWS 2000 3. Click “Internet Protocol TCP/IP” and click “Properties.” Select the “Use the following IP Address” option and insert 192.168.2.x (where x is 2 ~ 24, 26 ~ 254). Specify the default gateway and DNS server as indicated by your network administrator or Internet Service Provider. 4. Click “OK” and click “Close” to continue and save the changes.
CONFIGURING YOUR IP ADDRESS Windows XP 1. Right-click the “Network Places” icon on your desktop and click “Properties.” 2. Right-click your “Local Area Connection” and click “Properties.
WINDOWS XP 3. Click “Internet Protocol TCP/IP” and click “Properties.
CONFIGURING YOUR IP ADDRESS 4. Select the “Use the following IP Address” option and insert 192.168.2.x (where x is 2 ~ 24, 26 ~ 254) for the IP address. Specify the default gateway and DNS server as indicated by your network administrator or Internet Service Provider. 5. Click “OK” and click “Close” to continue and save the changes.
WEB MANAGEMENT Browser Configuration Confirm that your browser is configured for a direct connection to the Internet using the Ethernet cable that is installed in the computer. Disable Proxy Connection You will also need to verify that the HTTP Proxy feature of your web browser is disabled. This is so that your web browser will be able to view the SMC2870W configuration pages. The following steps are for Internet Explorer. Determine which browser you use and follow the appropriate steps.
WEB MANAGEMENT To access the SMC2870W’s management interface, enter the Wireless Ethernet Bridge IP address in your web browser http://192.168.2.25. Then enter the password and click LOGIN. (Default password: smcadmin) The home page displays the Setup options. Navigating the Web Browser Interface The SMC2870W’s web management interface features a user-friendly setup interface.
NAVIGATING THE WEB BROWSER INTERFACE Use the web management interface to define system parameters, manage and control the Wireless Ethernet Bridge and its ports, or monitor network conditions. The following table outlines the selections available from this program.
WEB MANAGEMENT System Password Settings Use this menu to restrict access based on a password. (Default: smcadmin). For security reasons, you should change the default password before exposing the SMC2870W to the Internet. Passwords can contain from 3 to 12 alphanumeric characters and are not case-sensitive. Enter a maximum Idle Time Out (in minutes) to define a maximum period of time for which the login session is maintained during inactivity.
NAVIGATING THE WEB BROWSER INTERFACE Operation Mode This may be set to Access Point, Client Bridge (Infrastructure, AdHoc), or Repeater. (Default: Access Point) Note: After you choose the operation mode for the SMC2870W, be sure to click the APPLY button, and click OK on the confirmation message to enable the new setting. These modes are described below: • Access Point – functions as a standard IEEE 802.
WEB MANAGEMENT LAN With “Obtain an IP Address Automatically [DHCP]” enabled, the IP address, subnet mask and default gateway can be dynamically assigned to the SMC2870W by the network DHCP server. Note: If there is no DHCP server on your network, then the SMC2870W will automatically start up with its default IP address, 192.168.2.25. The SMC2870W does not provide DHCP service. It simply passes client DHCP requests through to the DHCP server to obtain an IP Address.
NAVIGATING THE WEB BROWSER INTERFACE Wireless Settings To configure the SMC2870W as an Client Bridge, all you need to do is define the radio channel, the Service Set Identifier (SSID), and encryption options. In Client Bridge mode or Repeater mode, the radio channel and SSID (Service Set ID) of the SMC2870W must be set to the same values as those of the access point with which they are associated.
WEB MANAGEMENT Menu Description Wireless Channel The radio channel through which a wireless access point communicates with PCs in its BSS. (Default: 6) The available channel settings are limited by local regulations which determine the number of channels that are available. • USA: 1 ~ 11 channels • Europe: 1 ~ 13 channels • Japan: 1 ~ 14 channels 36 SSID All wireless clients and the wireles access points within a specific ESS must be configured with the same SSID.
NAVIGATING THE WEB BROWSER INTERFACE WEP Configuration If you are transmitting sensitive data across wireless channels, you should enable Wired Equivalent Privacy (WEP) encryption. Encryption requires you to use the same set of encryption/ decryption keys for a wireless access point and all of its wireless clients. The SMC2870W supports shared key encryption with key lengths of the 64-bit standard and 128-bit industry standard. The bit key must be in hexadecimal. (0~9, A~F, e.g., D7 0A 9C 7F E5.
WEB MANAGEMENT 64-Bit Manual Entry Key 1~4 - Each Key ID contains 10 HEX digits. 128-Bit Manual Entry Key ID contains 26 HEX digits. You may automatically generate encryption keys or manually enter the keys. For automatic 64-bit security, enter a passphrase. Four keys will be generated (as shown above). Choose a key from the four generated keys. Automatic 128-bit security generates a single passphrase.
NAVIGATING THE WEB BROWSER INTERFACE WPA Configuration WPA is a stronger wireless security solution than WEP. It uses a combination of authentication and broadcast/session keys. • Pre-Shared Key/Passphrase If there is no authentication server on your SOHO network, you can issue the Pre-Shared Key to the clients that connect to the Wireless Ethernet Bridge. Be sure to use the same key for the Wireless Ethernet Bridge and the connected clients.
WEB MANAGEMENT Notes: 1. Manual Pre-Shared Key supports up to 64-Hex characters. 2. Type 8~63 Hex characters for the Pre-Shared Passphrase.
NAVIGATING THE WEB BROWSER INTERFACE 3. Do not use a key that is long and complex for your clients to type accurately, as you might forget it. 4. A Hex (hexadecimal) digit is a number or letter in the range 0-9 or A-F. • 802.1X Mode The Wireless Ethernet Bridge allows you to use 802.1x authentication for an enterprise network environment with a RADIUS server installed. In 802.1x mode, access will be checked against the authentication database stored on the Wireless Ethernet Bridge.
WEB MANAGEMENT Client List The Client List screen displays the MAC address and network speed of the associated clients.
NAVIGATING THE WEB BROWSER INTERFACE MAC Address Filtering The MAC Address Filtering feature of the SMC2870W allows you to control access to your network clients based on the MAC (Media Access Control) Address of the client machine. This ID is unique to each network adapter. If MAC address filtering is enabled, then the MAC address for each client must be listed in the table to allow access to the network.
WEB MANAGEMENT Tools Use the Tools menu to back up the current configuration, restore a previously saved configuration, restore factory settings, update firmware, and reset the SMC2870W. Configuration Tools 44 • Backup Settings – Saves the SMC2870W’s configuration to a file. • Restore Settings – Restores settings from a saved backup configuration file. • Restore to Factory Defaults – Restores the SMC2870W settings back to the original factory defaults.
NAVIGATING THE WEB BROWSER INTERFACE Firmware Upgrade Use this screen to update the firmware or user interface to the latest version. Download the upgrade file from the web site and save it to your hard drive. Click Browse to look for the previously downloaded file. Click APPLY. Check the Status page Information section to confirm that the upgrade process was successful.
WEB MANAGEMENT Reset Click APPLY to reset the SMC2870W. Your settings will not be changed. The reset will be complete when the power LED is lit red.
NAVIGATING THE WEB BROWSER INTERFACE Status The Status screen displays WAN/LAN connection status, firmware, and hardware version numbers of the SMC2870W.
NETWORK CONFIGURATION AND PLANNING The Wireless Solution supports a stand-alone wireless network configuration, as well as an integrated configuration with 10 Mbps Ethernet LANs. For a list of the maximum distances between the AP/Bridge and wireless clients, refer to page 53.
NETWORK CONFIGURATION AND PLANNING Infrastructure Wireless LAN An integrated wired and wireless LAN is called an infrastructure configuration. A Basic Service Set (BSS) consists of a group of wireless PC users, and an access point that is directly connected to the wired LAN. Each wireless PC in this BSS can talk to any computer in its wireless group via a radio link, or access other computers or network resources in the wired LAN infrastructure via the access point.
NETWORK CONFIGURATION AND PLANNING Infrastructure Wireless LAN for Roaming Wireless PCs The Basic Service Set (BSS) is the communications domain for each wireless access point. For wireless PCs that do not need to support roaming, set the domain identifier (SSID) of the wireless card to the SSID of the access point to which you want to connect. Check with your administrator for the SSID of the access point to which he wants you to connect.
NETWORK CONFIGURATION AND PLANNING A Wireless LAN with Internet Access In this application one SMC2870W is in Client Bridge mode connected to a Microsoft Xbox. Another SMC2870W is acting in Access Point mode. This provides a wireless network and also Internet access for applications including Internet game playing.
TROUBLESHOOTING Check the following items before you contact technical support. 1. If mobile users do not have roaming access to the SMC2870W: Make sure that all the SMC2870Ws and stations in the ESS in which the WLAN mobile users can roam are configured to the same WEP setting, SSID, and authentication algorithm. 2. If the management utility cannot connect to the SMC: Check that your local IP address settings conform to the SMC2870W settings. 3.
NETWORK TOPOLOGIES Maximum Distance Table Important Notice Maximum distances posted below are actual tested distance thresholds. However, there are many variables such as barrier composition and construction and local environmental interference that may impact your actual distances and cause you to experience distance thresholds far lower than those posted below. 802.11b Wireless Distance Table Speed and Distance Ranges Environment 11 Mbps 5.
SPECIFICATIONS Standards IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX FastEthernet IEEE 802.11b IEEE 802.11g Data Rates 1/2/5.5/6/9/11/12/18/24/36/48/54 Mbps Frequency Band IEEE 802.11b/g Radio: 2.4 GHz USA FCC 2412~2462MHz (Ch1~Ch11) Canada - IC2412~2462MHz (Ch1~Ch11) Europe - ETSI 2412~2472MHz (Ch1~Ch13) Japan STD-T66/STD-332412~2484MHz (Ch1~Ch14) Modulation Type OFDM, CCKOperating Channels IEEE 802.11b/g compliant 11 channels (US, Canada) 13 channels (ETSI) 14 channels (Japan) Antenna Two 1.
SPECIFICATIONS Sensitivity Modulation Rate Modulation Rate Receive Sensitivity Typical (dBm) 802.11b - 1Mbps -90 802.11b - 2Mbps -88 802.11b - 5.5Mbps -85 802.11b- 11Mbps -82 802.11g - 6Mbps -88 802.11g - 9Mbps -87 802.11g - 12Mbps -84 802.11g - 18Mbps -82 802.11g - 24Mbps -79 802.11g - 36Mbps -75 802.11g - 48Mbps -68 802.
SPECIFICATIONS RF Output Power Modulation Rate Output Power (dBm) 802.11b - 1Mbps 16 802.11b - 2Mbps 16 802.11b - 5.5Mbps 16 802.11b- 11Mbps 16 802.11g - 6Mbps 15 802.11g - 9Mbps 15 802.11g - 12Mbps 15 802.11g - 18Mbps 15 802.11g - 24Mbps 15 802.11g - 36Mbps 15 802.11g - 48Mbps 12 802.11g - 54Mbps 12 Physical Size 14.30 x 12.20 x 3.03 cm (5.63 x 4.80 x 1.19 in.) Weight 150 g (5.
SPECIFICATIONS Temperature Operating: 0 to 40 °C (32 to 104 °F) Storage: -40 to 70 °C (-40 to 158 °F) Humidity 5% to 95% (non-condensing) LED Indicators Power, Ethernet Link/Activity, Wireless Activity (TX/RX) Network Management Windows 98SE/Me/2000/XP SNMP Management Utility Operating System Compatibility Windows 98SE/Me/2000/XP Supported Protocol TCP/IP, IPX Encryption 64-bit/128-bit WEP Passphrase key generation Compliances CE Mark EN55022 Class B EN55024 IEC 61000-42/3/4/6/11 Emissions FCC Part 15 Class
TERMINOLOGY The following is a list of terminology that is used in this document. Access Point – An internetworking device that seamlessly connects wired and wireless networks. Ad Hoc – An ad hoc wireless LAN is a group of computers each with LAN adapters, connected as an independent wireless LAN. Backbone – The core infrastructure of a network. The portion of the network that transports information from one central location to another central location where it is unloaded onto a local system.
TERMINOLOGY Ethernet – A popular local area data communications network, which accepts transmission from computers and terminals. Ethernet operates on a 10 Mbps baseband transmission rate, using a shielded coaxial cable or shielded twisted pair telephone wire. Infrastructure – An integrated wireless and wired LAN is called an Infrastructure configuration. Fragmentation Threshold – In the 802.11 Standard, the MAC Layer may fragment and reassemble directed MSDUs or MMPDUs.
TERMINOLOGY 60
