Table 4-1: General performance data
Environmental
Ambient Temperature
-34 ... +74
degree C
Shock
100
g
rms
Vibration
14
g
rms
IP
67
I
Pressure / Transport altitude
0…10.000
m
Mechanical
Weight
1320
g
Dimensions
See 5.2
Housing Identification
07
Antenna Identification
30
DSP Board Identification
12
General
Power Supply
7 ... 32
II
9
III
V DC
W
Frequency Band
24.0…24.25
GHz
Bandwidth
< 250
MHz
Max. Transmit Power (EIRP)
12.7
dBm
Interfaces
CAN V2.0b
RS485 full duplex
10/100 Ethernet
Connector
12 Pin plug Hirose LF10WBRB-
12PD
CAN, Power,
RS485, Eth.
I
IP 67 only when connector or cap attached.
II
measured at connector, min. voltage slew rate 500V/s or max. voltage rise time 15ms; supply source impedance
0.5Ohms.
III
Typical value 9W @20°C, may slightly increase over temperature.
4.4 Software and Firmware Version
The software in the UMRR-12 radar processor has Version 6.
