A P P E N D I X B
Remotely managing your system through an RS-232 serial interface
87 smarttech.com/kb/170401
Field Possible Values Description
current aspectratio l Fill
l match
l 16:9
The ranges must match the OSD ranges
target projectionmode l = front
l = ceiling
l = rear
l = rear ceiling
The ranges must match the OSD ranges
current projectionmode l = front
l = ceiling
l = rear
l = rear ceiling
The ranges must match the OSD ranges
target startupscreen l = smart
l = usercapture
l = preview
The ranges must match the OSD ranges
current startupscreen l = smart
l = usercapture
l = preview
The ranges must match the OSD ranges
current reset l done Sent once the reset has been performed.
current lamphrs l 0 ~ 5000 Current lamp hour usage
target lamphrs l 0 Clear the current lamp hour usage. Zero is the
only valid value to be written.
current resolution l 800x600
l 1024x768
l …
l no signal
Current resolution of the input. Current resolution
of the input. If no signal is detected,
‘resolution=no signal’ should be returned
native aspect ratio l 4:3 for UF70,
16:10 for UF70w
Native aspect ratio (kind of hardware settings).
DLP resolution of the projector. Return the actual
native aspect ratio of the projector.
current fwverddp l [?].[?].[?].[?] Current firmware version. Eg 2.0.0.0
current fwvernet l [?].[?].[?].[?] Network Processor Version
current fwvermpu l [?].[?].[?].[?] MPU Version
current prjserialnum l [?????????????] Projector Serial Number
