A P P E N D I X B
Remotely managing your system through an RS-232 serial interface
86 smarttech.com/kb/170401
Field Possible Values Description
target highbrightness l = on
l = off
The ranges must match the OSD ranges
current highbrightness l on
l off
The ranges must match the OSD ranges
target autopoweroff l + val
l – val
l = 0 ~ 240
The ranges must match the OSD ranges
current autopoweroff l + val
l – val
l = 0 ~ 240
The ranges must match the OSD ranges
target zoom l + val
l – val
l = 0 ~ 30
The ranges must match the OSD ranges
current zoom l = 0 ~ 30 The ranges must match the OSD ranges
target projectorid l + val
l – val
l = 0 ~ 999
The ranges must match the OSD ranges
current projectorid l = 0 ~ 999 The ranges must match the OSD ranges
target aspectratio l = fill
l = match
l = 16:9
The ranges must match the OSD ranges.
Fill:
No matter what the input, the image is stretched,
scaled etc to produce an image that matches the
DMD device. So 16:9 in = 4:3 out for the XGA
projector and 16:9 in = 16:10 out for the WXGA
Match:
The signal is scaled such that the input aspect
ration is what is displayed. So 4:3 in = 4:3 out.
16:10 in = 16:10 in. 4:5 in = 4:5 out.
16:9
The signal is scaled and stretched to produce a
16:9 image.
