User manual

A P P E N D I X B
Remotely managing your system through an RS-232 serial interface
77 smarttech.com/kb/170401
target magenta l + val
l – val
l = 0 ~ 100
The ranges must match the OSD ranges
current magenta l = 0 ~ 100 The ranges must match the OSD ranges
target yellow l + val
l – val
l = 0 ~ 100
The ranges must match the OSD ranges
current yellow l = 0 ~ 100 The ranges must match the OSD ranges
target videofreeze l = on
l = off
Video Freeze on/off
current videofreeze l = on
l = off
Video Freeze on/off
current displayhide l normal
l frozen
l muted
Matches the 3 states of the hide button on the IR
remote controller
target displayhide l normal
l frozen
l muted
l next
Allows for setting of the mode directly or to move
from one state to the next sequentially.
The above commands can be used to set the property to an absolute value or cause a relative
adjustment to be made to the current value. Examples of using this are below:
>get brightness
brightness=55
>set brightness = 65
brightness=65
>set brightness +5
brightness=70
>set brightness-15
brightness=55
>
