target hposition l + val
l – val
l = 0 ~ 100
The ranges must match the OSD ranges
current hposition l = 0 ~ 100 The ranges must match the OSD ranges
target vposition l + val
l – val
l = -5 ~ +5
The ranges must match the OSD ranges. Values
depend upon the source?
current vposition l = -5 ~ +5 The ranges must match the OSD ranges
target whitepeaking l + val
l – val
l = 0 ~ 10
The ranges must match the OSD ranges
current whitepeaking l = 0 ~ 10 The ranges must match the OSD ranges
target degamma l + val
l – val
l = 0 ~ 3
The ranges must match the OSD ranges
current degamma l = 0 ~ 3 The ranges must match the OSD ranges
target red l + val
l – val
l = 0 ~ 100
The ranges must match the OSD ranges
current red l = 0 ~ 100 The ranges must match the OSD ranges
target green l + val
l – val
l = 0 ~ 100
The ranges must match the OSD ranges
current green l = 0 ~ 100 The ranges must match the OSD ranges
target blue l + val
l – val
l = 0 ~ 100
The ranges must match the OSD ranges
current blue l = 0 ~ 100 The ranges must match the OSD ranges
target cyan l + val
l – val
l = 0 ~ 100
The ranges must match the OSD ranges
current cyan l = 0 ~ 100 The ranges must match the OSD ranges
